Kubernetes for ML: Deploying Models at Scale with Kserve

You’ve built a FastAPI server. It’s containerized. You can run it on a single machine. But what happens when you need to serve 1000 concurrent users? What about zero-downtime model updates? Or rolling back a bad model? Or sharing GPU resources across multiple teams?

This is where Kubernetes comes in — and specifically Kserve, the open-source model serving platform built on Kubernetes that powers production ML at companies like Bloomberg, Uber, and Spotify.

Why Kubernetes for ML?

Kubernetes provides the orchestration layer that turns a collection of GPU machines into a unified serving platform:

• Auto-scaling: Scale from 0 to 100 replicas based on request load
• GPU scheduling: Assign GPUs to pods that need them, share GPUs between lightweight models
• Rolling updates: Update models without dropping requests
• Resource isolation: Separate models into namespaces with guaranteed resources
• Observability: Prometheus metrics, structured logging, distributed tracing

The Minimal Service Architecture

                     ┌─────────────┐
                     │  Ingress    │  (Traefik / nginx / Istio)
                     │  Controller │
                     └──────┬──────┘
                            │
                     ┌──────▼──────┐
                     │  Kserve     │  (Inference CRDs + routing)
                     │  Controller │
                     └──────┬──────┘
                            │
              ┌─────────────┼─────────────┐
              │             │             │
        ┌─────▼────┐  ┌────▼────┐  ┌────▼────┐
        │ Model A  │  │ Model B │  │ Model C │  (Inference pods)
        │ v1.2.3   │  │ v2.0.0  │  │ v1.0.0  │
        │ GPU pod  │  │ GPU pod │  │ CPU pod │
        └──────────┘  └─────────┘  └─────────┘

Setting up Kserve

Prerequisites

A Kubernetes cluster with GPU nodes. For local development, we use kind (Kubernetes in Docker):

# Create a GPU-capable kind cluster
cat <<EOF | kind create cluster --config=-
kind: Cluster
apiVersion: kind.x-k8s.io/v1alpha4
nodes:
  - role: control-plane
  - role: worker
    extraMounts:
      - hostPath: /var/run/nvidia
        containerPath: /var/run/nvidia
EOF

# Install NVIDIA GPU operator
helm install gpu-operator nvidia/gpu-operator \
    --set driver.enabled=false  # if drivers already installed on host

Install Kserve

# Add Kserve helm repo
helm repo add kserve https://kserve.github.io/helm-charts
helm repo update

# Install Kserve with Istio ingress
helm install kserve kserve/kserve \
    --namespace kserve --create-namespace \
    --set ingress.enabled=true \
    --set ingress.ingressGateway=istio-ingressgateway/istio-ingressgateway

# Verify installation
kubectl get pods -n kserve
# Should see: kserve-controller-manager-xxx   Running

Deploying Your First Model

Kserve introduces the InferenceService custom resource — you define your model in YAML, and Kserve handles everything else.

Serving a Scikit-learn Model

# sklearn-model.yaml
apiVersion: "serving.kserve.io/v1beta1"
kind: "InferenceService"
metadata:
  name: "iris-classifier"
spec:
  predictor:
    sklearn:
      storageUri: "gs://my-bucket/iris-model/"
      resources:
        requests:
          cpu: "500m"
          memory: "512Mi"
        limits:
          cpu: "1"
          memory: "1Gi"

Serving a PyTorch Model with GPU

# pytorch-gpu-model.yaml
apiVersion: "serving.kserve.io/v1beta1"
kind: "InferenceService"
metadata:
  name: "resnet-classifier"
spec:
  predictor:
    pytorch:
      storageUri: "s3://ml-models/resnet18/model.pt"
      resources:
        requests:
          cpu: "2"
          memory: "8Gi"
          nvidia.com/gpu: "1"
        limits:
          cpu: "4"
          memory: "16Gi"
          nvidia.com/gpu: "1"
    minReplicas: 0
    maxReplicas: 5

Key fields:

• storageUri: Where the model artifact lives (GCS, S3, Azure Blob, PVC, or local)
• resources.requests.nvidia.com/gpu: Request 1 GPU — Kserve schedules this pod on a GPU node
• minReplicas / maxReplicas: Horizontal Pod Autoscaler configuration
• minReplicas: 0: Scale to zero when idle (saves GPU costs)

Deploying a vLLM-based LLM

For LLMs, you typically use a custom container image with vLLM:

# llm-inference.yaml
apiVersion: "serving.kserve.io/v1beta1"
kind: "InferenceService"
metadata:
  name: "llama3-8b"
spec:
  predictor:
    containers:
      - name: kserve-container
        image: vllm/vllm-openai:latest
        args:
          - "--model"
          - "meta-llama/Meta-Llama-3.1-8B-Instruct"
          - "--tensor-parallel-size"
          - "1"
          - "--max-model-len"
          - "8192"
          - "--gpu-memory-utilization"
          - "0.90"
        ports:
          - containerPort: 8000
            protocol: TCP
        env:
          - name: HUGGING_FACE_HUB_TOKEN
            valueFrom:
              secretKeyRef:
                name: hf-token
                key: token
        resources:
          requests:
            nvidia.com/gpu: "1"
            memory: "32Gi"
          limits:
            nvidia.com/gpu: "1"
            memory: "64Gi"
    minReplicas: 0
    maxReplicas: 3

Apply the configuration:

kubectl apply -f llm-inference.yaml

# Check the status
kubectl get inferenceservice llama3-8b

# NAME         URL                                                  READY
# llama3-8b    http://llama3-8b.kserve.example.com/v1/chat/completions   True

Auto-Scaling: From 0 to 100 and Back

Kserve integrates with Kubernetes’ Horizontal Pod Autoscaler (HPA) and can also use Keda for event-driven scaling.

Concurrency-Based Scaling

The default scaling metric is CPU, but for inference you typically want concurrency-based scaling:

spec:
  predictor:
    minReplicas: 0
    maxReplicas: 10
    scaleMetric: concurrency
    scaleTarget: 5  # Target 5 concurrent requests per pod

When requests spike beyond 5 per pod, Kserve spins up new pods. When traffic drops, it scales back down — even to zero, freeing GPU resources.

Scale-from-Zero Latency

Scaling from zero takes ~30–60 seconds (pulling the container image and loading the model). For latency-sensitive applications:

• Keep a minimum running replica (minReplicas: 1)
• Pre-pull images on all nodes using DaemonSets
• Use model caching with a shared PVC or sidecar that pre-warms

GPU Scheduling

Kubernetes manages GPUs through the device plugin framework. The NVIDIA device plugin exposes GPUs as schedulable resources:

# Check GPU availability
kubectl get nodes -o custom-columns=NAME:.metadata.name,GPU:.status.allocatable.nvidia\\.com/gpu

# Check which pods are using GPUs
kubectl get pods -o custom-columns=NAME:.metadata.name,GPU_REQUEST:.spec.containers[*].resources.limits.nvidia\\.com/gpu

GPU Sharing Strategies

Strategy	Method	Isolation	Use Case
Exclusive GPU	nvidia.com/gpu: 1	Full	Large models, critical services
MIG (A100/H100)	nvidia.com/mig-*.slices	Hardware	Multi-tenant, guaranteed perf
Time-slicing	Config in device plugin	Software	Dev/test, non-critical workloads
MPS	CUDA MPS daemon	Memory-based	Small models, best-effort

For most production use, exclusive GPU assignment is simplest and safest. MIG is worth the complexity for truly multi-tenant clusters.

Rolling Updates and Canary Deployments

Kserve supports progressive delivery natively. To deploy a new model version safely:

# canary-deploy.yaml
apiVersion: "serving.kserve.io/v1beta1"
kind: "InferenceService"
metadata:
  name: "my-model"
spec:
  predictor:
    canary:
      storageUri: "s3://models/my-model-v2/"
      trafficPercent: 10  # Send 10% of requests to new version
    resources:
      nvidia.com/gpu: 1

This creates a canary deployment receiving 10% of traffic. Once you confirm it’s working:

# Promote canary to 100%
kubectl patch inferenceservice my-model \
    --type='merge' \
    -p='{"spec":{"predictor":{"canaryTrafficPercent":100}}}'

# Or rollback by deleting the canary spec
kubectl patch inferenceservice my-model \
    --type='json' \
    -p='[{"op": "remove", "path": "/spec/predictor/canary"}]'

Monitoring with Prometheus

Kserve exposes Prometheus metrics automatically. Each inference pod emits:

• request_count: Total inference requests
• request_latency: Latency buckets (50ms, 100ms, 250ms, 500ms, 1s, 5s)
• response_count: Responses by status code
• inference_service_running: Whether the service is healthy

Sample Prometheus Query

# P99 latency over the last 5 minutes
histogram_quantile(0.99,
  sum(rate(request_latency_bucket{service_name="llama3-8b"}[5m])) by (le)
)

# Request rate (per second)
rate(request_count{service_name="llama3-8b"}[5m])

# GPU utilization across all model pods
avg(nvidia_gpu_utilization{kubernetes_pod_name=~"llama3-8b-.*"})

Setting up a Dashboard

# grafana-dashboard.yaml (excerpt)
panels:
  - title: "Request Rate"
    type: timeseries
    targets:
      - expr: rate(request_count{namespace="kserve"}[5m])
  - title: "P99 Latency"
    type: gauge
    targets:
      - expr: histogram_quantile(0.99, rate(request_latency_bucket[5m]))
  - title: "GPU Memory"
    type: timeseries
    targets:
      - expr: nvidia_memory_used_bytes / nvidia_memory_total_bytes

Production Checklist

Deploying ML on Kubernetes is more than writing YAML. Here’s what you need for production:

Security

• Pull model images from a private registry (ECR, GCR, Harbor)
• Store secrets (HF tokens, S3 keys) in Kubernetes Secrets or Vault
• Run containers as non-root with read-only root filesystem
• Network policies restricting pod-to-pod communication

Reliability

• Pod disruption budgets (PDB) to prevent all replicas from being evicted
• Resource requests = resource limits (to avoid noisy neighbors)
• Liveness and readiness probes configured
• Graceful shutdown handling (SIGTERM → finish current requests → exit)

Cost

• Scale-to-zero for non-production environments
• Spot instances for batch inference and training
• GPU node auto-scaling (Cluster Autoscaler or Karpenter)

Observability

• Prometheus metrics exported from every inference pod
• Grafana dashboards for latency, throughput, and GPU utilization
• Structured JSON logging (not ad-hoc print statements)
• Distributed tracing for multi-model pipelines

Common Pitfalls

Cold Starts Are Real

When scaling from zero, loading a large model (70B parameters) can take 2–5 minutes. Mitigations:

• Pre-warm models on dedicated nodes
• Use PVC-backed model caches
• Accept that scale-from-zero adds latency and plan SLAs accordingly

GPU Fragmentation

If you have 4 models each requesting 1 GPU but you have 4 GPUs on 1 node, a single node failure takes down all models. Use pod anti-affinity to spread replicas across nodes:

spec:
  predictor:
    affinity:
      podAntiAffinity:
        preferredDuringSchedulingIgnoredDuringExecution:
          - weight: 100
            podAffinityTerm:
              labelSelector:
                matchLabels:
                  app: my-model
              topologyKey: "kubernetes.io/hostname"

OOM Kills Without Graceful Degradation

If a model’s memory grows beyond its limits (e.g., KV cache with very long sequences), Kubernetes will kill the pod without finishing requests. Set memory limits slightly above your expected usage and add admission control for request sizes.

Summary

Kubernetes + Kserve gives you a production-grade model serving platform that scales, self-heals, and handles multi-model deployments. The key concepts are:

1. InferenceService CRD defines the model, resources, and scaling policy
2. Scale-to-zero saves GPU costs when models aren’t in use
3. Canary deployments enable safe rollouts of new model versions
4. Prometheus metrics give visibility into every model’s performance
5. GPU scheduling ensures GPUs are used efficiently

In the next post, we’ll look at ML CI/CD — automating the pipeline from training → registration → deployment so you never manually deploy a model again.
